Pluggable interface relay 24VAC, 12 amps

ABB's Cr-M024AC2L pluggable interface relay operates with a 24 volts AC-rated control supply voltage. From the CR-M (miniature) relay range, it has a two c/o (SPDT) output with contacts rates at 250 volts and 12 amps. The miniature interface relay has IP40 protection for safety and is certified to UL 508 standards.

FEATURES

• Integrated orange test button for manual actuation and locking of output contacts
• Integrated LED

SPECIFICATIONS

Type: Pluggable interface relay

Function: Pluggable miniature interface relay CR-M

Contact configuration: 2CO SPDT

Contact rating: B300

Terminal type: Flat plug-in connector

Insulated voltage: 250 volts

Current rating: 12 amps

Voltage rating: 24 VAC

Output: 2 c/o (SPDT) contacts

Output signal: 250 volts/12 amps

Operational temperature: -40 to 55 deg C

Width: 21.2mm

Height: 35.6mm

Length: 27.5mm

Weight: 0.33kg

Protection rating: IP40

Units: Each
