Pressure switch 3/1100 10amp overload port 415V

The pressure switch boasts a switching capacity of 2.2kW.

FEATURES

• Threee phase
• Switching capacity 7.52kW/20hp
• Available with overload relay/scale/auxiliary switch
• Maximum cut-out pressure 35 bar
• Three pole (NC)
• Diecast aluminium flange

SPECIFICATIONS

Pressure range: 400-1100kPa

Connection: 1/4" BSP F

Rated insulation: 690 volts

Motor switching capacity: 7.5kW

Weight: 680g

Units: Each
