Inline fuse switch disconnector - 1P, 630A XLBM3

FEATURES

• Three pole
• Includes six M8 x 16mm bolts

SPECIFICATIONS

Rated operational current AC-21B (Ie): (690 volts) 630 amps

Rated operational current AC-22B (Ie): (500 volts) 630 amps

Rated operational current A-23B (Ie): (380-415 volts) 500 amps

Rated impulse withstand voltage: 8kV

Rated operational voltage: Main circuit 50/60kV

Handle type: 1P

Fuse size: NH3

Mounting type: 185mm Busbar/support mounting facilities

Number of poles: 3

Degree of protection: according to IEC 60529 IP30

Terminal type: Bolt

Width: 10mm

Height: 66mm

Depth/width: 17.8mm

Weight: 5.2kg

Units: Each
